Boaters' Resale Shop of TX 2511 0101.57 XANTREX LinkPRO BATTERY MONITOR 84-2031-00 with FLUSH MOUNT RING ONLY * 500 AMP SHUNT & WIRING NOT INCLUDED(WIRING FOR TESTING ONLY) * SEE ALL 6 PHOTOS & DETAILS * SOLD IN CONDITION PICTURED * SOME ASSEMBLY MAY BE REQUIRED WHEN SHIPPED * ITEM WAS PREOWNED, USED, IS IN FAIR PHYSICAL CONDITION AND APPEARS TO BE OPERATING PROPERLY, POWERS UP AND CONTROLS WORK BUT HAS NOT BEEN TESTED FURTHER

Description
The LinkPRO can measure currents up to 10,000 Amps. It selectively displays voltage, charge and discharge current, consumed amp hours remaining battery capacity and the time remaining of your battery bank. It is equipped with an internal programmable alarm relay, to run a generator when needed or to turn off devices when the battery voltage exceeds programmable boundaries.

Defining the amount of energy available in a battery is a complex task since battery age, discharge current and temperature all influence the actual battery capacity. High performance measuring circuits, along with complex software algorithms, are used to exactly determine the remaining battery capacity and the time remaining of your battery bank. A new shunt selection feature enables the Link PRO to measure currents up to 10,000 Amps.

Using a clear backlit LCD Display and an intuitive user interface, all parameters can be recalled with just a button press. A second battery input is also provided to monitor voltage on a second battery. It is equipped with an internal programmable alarm relay, to run a generator when needed or to turn off devices when the battery voltage exceeds programmable boundaries.
Features
Read your battery bank like a fuel gauge
Provides critical information about the status of your battery bank
Displays voltage, current, consumed amp hours and remaining battery capacity
Secondary battery bank voltage monitoring
Auto sensing battery voltage inputs
Large backlit LCD Display
Quick nut mounting construction
Programmable alarm relay
Shunt selection capability enables flexible system integration
Splash proof front panel
CE and e-mark certified
Displays time remaining
Communication/expansion port
Stores a wide range of history events in internal memory
Advanced programmable alarm relay
Battery temperature sensor input
Connection Kit Sold Separately
Specifications:
Measures currents up to 1,000 Amps
Supply Voltage Range: 9 to 35V DC
Input Voltage Range:
Main battery 0 to 35V DC
Auxiliary battery: 2 to 35V DC
Front Panel Dimensions: 2.54" (64mm)
Body Diameter: 2.05" (52mm)
Total Depth: 3.11" (79mm)
